Features:
Class-D Amplifier Technology - The highly efficient Class-D design provides 1400-Watts peak power whilst drawing less current than a standard Class-AB amplifier. This design provides increased efficiency and power output to your speakers, letting you enjoy your music for longer.
1400 Watts peak power - Easily power 4 speakers, or 2 speakers and a subwoofer with a peak power of 1400 Watts.
Marine-Ready Design with Conformal Coated PCBs - Extending the life of your amplifiers, the Signature Series are designed specifically for marine use with conformal coated PCBs to provide extra protection from the marine elements.
Rigid Aluminum Alloy Heat Sink - Molded to form a singular die-cast chassis, the fin layout is calculated with precision to increase the surface area of the heat sink and improve heat dissipation.
Stainless Mirror Finish - The polished stainless-steel control panel cover conceals and protects all cable connections and settings controls whilst providing an attractive finish to complement any installation.
Speaker Configuration - Whether you require 2 Ohms per channel or 4 Ohms bridged, your Signature Series amplifier has your installation options covered to achieve the optimum output levels.
Connect up to two speakers per channel at 2 Ohms, or for extra power, bridge two channels at 4 Ohms to connect two subwoofers.
Zone Designation - To align with the Fusion entertainment system zone philosophy, the input and output connections are labelled as zones.
True-Marine Design - Signature Series amplifiers are perfect for the marine environment, and carry a 3-year warranty.
Product Specifications
| Amplifier Class |
Class-D |
| Frequency Response |
10Hz - 65kHz |
| Peak Power |
1400 Watts |
| Rated Power (4 Ohms) |
150 Watts RMS x 4 @ 14.4V - 4 Ohms 1% THD |
| Rated Power (2 Ohms) |
220 Watts RMS x 4 @ 14.4V - 2 Ohms 1% THD |
| Rated Power (4 Ohms Bridged) |
440 Watts RMS x 2 @ 14.4V - 4 Ohm Bridged 1% THD |
Mounting Dimensions
| Length |
300mm [11-13/16”] |
| Depth |
210mm [8-1/4”] |
| Height |
50mm [2”] |
