Features:
• Small size for discreet installation (128mm x 78mm x 51mm)
• 140 watt (70W x 2) peak power output with two channels.
• Class-D amplifier technology – for a high output with low battery drain
• 2 Ohm stable stereo
• Conformal coated PCB – extends product life and performance
• Water resistant design
• Variable high pass filter
• Selectable high pass/full range setting
• Audio-detect function available – the amplifier will turn on when audio is detected and switches to low power mode/sleep when audio is not present.
• Rated True-Marine with 3-year warranty
Product Specifications
Amplifier Class |
Class-D |
Peak Power |
140 Watts |
Rated Power (4 Ohms) |
20 Watts RMS x 2 @ 14.4V - 4 Ohms 10% THD |
Rated Power (2 Ohms) |
30 Watts RMS x 2 @ 2 Ohms 10% THD |
Operating Voltage |
10 -16 Volts DC |
Warranty |
3 Year Warranty |
Mounting Dimensions
Length |
128mm (5-1/16") |
Depth |
78mm (3-1/16") |
Height |
51mm (2") |
