Features:
400W peak power output to power up to four speakers
Class-AB amplifier – power efficient with less cross-over distortion
Conformal coated PCBs – water resistant protection from salt air and moisture
FUTRANZ heat sink technology – transfers heat more efficiently and provides more thermal stability with maximum component reliability
F.R.A.T (Fusion Regulated Amplifier Technology) – provides enormous power output at low voltage.
F.I.S.T (Fusion Intercooled Semi-Conductor Technology) – clamps down internal power switching to rapidly remove heat from all associated semi-conductors
1 year limited Consumer Warranty
Product Specifications
| Amplifier Class |
Class-AB |
| Rated Power (2 Ohms) |
100 Watts RMS x 2 @ 14.4V - 2 Ohms 1% THD |
| Rated Power (4 Ohms Bridged) |
200 Watts RMS x 1 @ 14.4V - 4 Ohms Bridged 1% THD |
Amplifier Specifications
| Frequency Response |
5Hz - 38kHz +/- 3dB |
| Peak Power |
400 Watts |
| Rated Power (4 Ohms) |
65 Watts RMS x 2 @ 14.4V - 4 Ohms 1% THD |
Mounting Dimensions
| Length |
296mm [11-/2/3"] |
| Depth |
229mm [9"] |
| Height |
53mm [2-1/16"] |
