| Tuner |
AM/FM with RDS |
| Amplifier |
Class-D 4 x 70W (@ 2 Ω) |
| Audio Zones |
3 Zones (Zone 1 & 2 powered by internal amplifier) |
| Nameable Zones |
Yes |
| Line Out |
3 (1 x L + R per zone, all require amplification) |
| Sub Out |
3 (1 per zone) |
| Auxiliary |
2 stereo inputs |
| iPod/iPhone |
Made for iPod and iPhone (1 A charging) |
| Display |
128 x 64 Monochrome Optically Bonded LCD |
| NMEA 2000 |
NMEA 2000 Certified LEN: 1 |
| FUSION-Link |
via NMEA 2000 (visit www.fusion-link.com for compatible Multi-Function Displays (MFDs) or Bluetooth remote control via compatible Apple or Android devices |
| Bluetooth |
A2DP Audio Streaming with AVRCP Support and Fusion-Link remote control |
| USB |
1 x USB connector |
| MTP |
Support for compatible Windows & Android media devices via USB |
| Audio Format |
MP3, M4A, FLAC, CDA, DVD |
| SiriusXM-Ready |
(USA Only.) Requires optional SiriusXM Connect vehicle tuner |
| DVD Playback |
DVD Playback with composite and component video connections |
| CD Playback |
CD/CD-R disks supported |
| Water Resistance (IP Rating) |
360° IPX5 water resistant fully sealed chassis |
| Chassis |
Glass Filled Composite with Aluminum Heat Sink |
| DAB+ Ready |
MS-DAB100A is required for DAB support, only available where DAB and DAB+ is broadcast |
| Dimensions: Length x Height x Depth (Front Panel incl. Volume Encoder) |
216mm x 78mm x 35mm [8-1/2" x 3-1/16" x 1-3/8"] |
| Mounting Dimensions: Height x Depth |
52mm x 177mm [2-1/16" x 7"] |
