A long lasting battery made with the highest quality
Battery specification
|
No.
|
Item
|
General Parameter
|
Remark
|
|
1
|
Rated Capacity
|
Typical
|
2200mAh
|
Standard discharge ( 0.2C) after standard charge
( 0.2C )
|
|
Minimum
|
2200mAh
|
|
2
|
Nominal Voltage
|
3.7V
|
Mean Operation Voltage
|
|
3
|
Voltage at end of Discharge
|
2.7V
|
Discharge Cut-off Voltage
|
|
4
|
Charging at end of Voltage
|
4.2V
|
|
|
5
|
Standard charge
|
Constant Current 0.5C Constant Voltage 3.65V 0.02C cut-off
(:0.2C :3.65V :
0.02C)
|
Charge time:Approx 8.0h
|
|
6
|
Standard discharge
|
Constant Current 0.2C end Voltage 2.0V
(:0.2C 2.0V)
|
|
|
8
|
Fast charge
|
Constant Current 1C Constant Voltage 3.65V 0.01C cut-off
(:1C :3.65V
:0.01C)
|
Charge time:Approx 2.5h
(: 2.5 )
|
|
9
|
Fast discharge
|
Constant Current 1C end Voltage 2.0V
(:1C 2.0V)
|
|
|
10
|
Maximum Continuous Charge Current
|
1C
|
|
|
11
|
Maximum Continuous Discharge Current
|
3C
|
|
|
12
|
Operation Temperature Range
|
Charge:0~45ºC
|
60±25%R.H. Bare Cell
|
|
Discharge:-20~60ºC
|
|
13
|
Storage Temperature Range
|
Less than 1 year:-20~25ºC
( 1 :-20~25ºC)
|
60 ± 25%R.H. at the shipment state()
|
|
Less then 3 months:-20~40ºC
( 3 :-20~40ºC)
|
|
14
|
IR
|
≤60mΩ
|
|
|
15
|
Weight
|
Approx:46±1g
|
|
