Features:
Versatile Design: With versatile options for integrating your subwoofer into your audio system, you can customize your setup to suit your audio requirements. Wire your subwoofer traditionally through an amplifier or create a 2.1 audio zone by connecting your subwoofer and two speakers directly to a compatible Fusion stereo with DSP, like the Apollo Series, without requiring an external amplifier.
Quality Audio Reproduction: Enjoy quality low frequency audio at any volume level.
True-Marine™ Designed and Engineered: Extensively tested to perform in the harsh marine environment, the XS Series carry an IP65 weatherproof rating with a 3-year warranty.
Two Grille Options Supplied: Enjoy the freedom to choose the finish to suit your boat, with both Classic Black and Classic White grilles supplied in the box.
Designed To Comply With ISO12216: Tested to international standards for pressure and watertightness, it recognizes the XS Series are designed and built to the highest industry standards for quality and robustness.
Product Specifications
|
Subwoofer Size
|
10"
|
|
Peak Power
|
600 Watts
|
|
RMS Power Rating
|
120 Watts
|
|
Efficiency (1W/1M)
|
87dB
|
|
Frequency Response
|
30 Hz - 2 kHz
|
|
Nominal Impedance
|
4 ohms
|
|
Recommended Amplifier Power (RMS)
|
40 - 300 W/Ch
|
|
Cone / Surround Material
|
Polypropylene with rubber surround
|
|
Mounting Diameter Clearance
|
223mm (8-3/4")
|
|
Mounting Depth Clearance
|
113mm (4-7/16")
|
|
Optimum Enclosure Volume (Sealed enclosure, fully filled with absorption material)
|
40 L
|
|
Operating Temperature Range
|
0 to 50°C (32 to 122°F)
|
|
Storage Temperature Range
|
-20 to 70°C (-4 to 158°F)
|
|
Water and Dust Resistance (IP rating)
|
IP65
|
|
Subwoofer Dimensions: Length x Height x Depth
|
Ø 274mm x 142mm [Ø 10-13/16" x 5-9/16"]
|
|
Warranty
|
3 years
|
