Physical Dimensions (WxHxD)
|
6.18” x 2.68” x 4.06” (156.9 x 68 x 103.2 mm)
|
|
Weight
|
11.1 oz (316 g)
|
|
Water Rating
|
IPX6 and IPX7 (front panel only, when properly installed)
|
|
Power Input
|
10.8-16 VDC
|
|
Operating Temperature Range
|
32° to 122° F (0° to 50° C)
|
|
Current (Max.)
|
15 A
|
|
BLUETOOTH® Wireless Range
|
Up to 30 ft (10 m)
|
|
ANT® Wireless Range
|
Up to 10 ft (3 m)
|
|
Wireless Frequencies/Protocols
|
BLUETOOTH 2.4 GHz @ +12 dBm nominal / ANT 2.4 GHz @ +7 dBm nominal
|
|
Compass-Safe Distance
|
5.9” (150 mm)
|
|
Display
|
2.3” perimeter bonded monochrome dot matrix LCD
|
|
Built-In Amplifier
|
Class-D (minimum 4 ohm impedance)
|
|
Peak Power
|
180 W
|
|
Rated Power Output (4 ohm)
|
22 W rms x 4 @ 14.4 V input, 4 ohm, 10% THD
|
|
Fusion-Link Control
|
Yes (with compatible Apple® and Android devices)
|
|
Fusion-Link Lite Control
|
Yes (with compatible Garmin watch)
|
|
Multi-Zone Technology
|
2 zones
|
|
BLUETOOTH Wireless Technology
|
Yes
|
|
ANT Wireless Technology
|
Yes
|
|
DAB+
|
Yes (DAB tuner built-in)
|
|
Multi-Language Interface
|
Dutch / English / French / German / Italian / Spanish
|
|
Software Updates
|
Over-the-air software updates via BLUETOOTH wireless technology using the Fusion-Link app
|
|
Warranty
|
1 year
|
|
Sources
|
AM / FM / BLUETOOTH / AUX x1 / DAB+ (available in Europe and Australia only)
|
|
Auxiliary Input
|
One RCA input (AUX)
|
|
AM / FM Radio
|
One Motorola antenna connector port
|
|
Speaker
|
4 x speaker connections (2 amplified zones)
|
|
RCA Pre-Out (Left, Right and Subwoofer)
|
1 zone (requires external amplification)
|
|
Line Out
|
Zone 1: L + R (requires external amplification)
|
|
Subwoofer Out
|
Zone 1 (requires external amplification)
|
