Features:
Optimized Full Range Speaker: The XS Series speakers are acoustically optimized for performance in the marine environment, by combining optimized speaker drivers and tweeters to produce quality sound at all volumes.
Innovative RGB Illuminated Cone: Enhance your on-water audio entertainment experience with LED illumination in a range of colors. The innovative translucent cone disperses a bright, even illumination to set the tone on board.
True-Marine™ Designed and Engineered: Extensively tested to perform in the harsh marine environment, the XS Series carry an IP65 weatherproof rating with a 3-year warranty.
Two Grille Options Supplied: Enjoy the freedom to choose the finish to suit your boat, with both Sports Gray and Sports White grilles supplied in the box.
Designed To Comply With ISO12216: Tested to international standards for pressure and watertightness, it recognizes the XS Series are designed and built to the highest industry standards for quality and robustness.
Product Specifications
| Speaker Size |
7.7" |
| Peak Power |
240 Watts |
| RMS Power Rating |
60 Watts |
| Efficiency (1W/1M) |
92dB |
| Frequency Response |
70 Hz - 18 kHz |
| Nominal Impedance |
4 ohms |
| Recommended Amplifier Power (RMS) |
25 - 200 W/Ch |
| Tweeter Type |
Aluminum dome |
| Cone / Surround Material |
Polypropylene with cloth surround |
| Mounting Diameter Clearance |
162mm (6-3/8") |
| Mounting Depth Clearance |
77mm (3") |
| Optimum Enclosure Volume (Sealed enclosure, fully filled with absorption material) |
10 L |
| LED Color Options |
RGB |
| LED Supply Voltage |
10.8 to 16V dc |
| LED Load Current at 14.4V dc |
150mA |
| Operating Temperature Range |
0 to 50°C (32 to 122°F) |
| Storage Temperature Range |
-20 to 70°C (-4 to 158°F) |
| Water and Dust Resistance (IP rating) |
IP65 |
| Speaker Dimensions: Length x Height x Depth |
Ø 196mm x 97mm [Ø 7-11/16" x 3-13/16"] |
| Warranty |
3 years |
