Product Specifications

Display 2.7" optically bonded color LCD

Sources                AM / FM / Bluetooth / USB audio / iPhone / iPod / AUX / MTP / SiriusXM-Ready (USA only, requires optional SiriusXM Connect Vehicle Tuner) / DAB+ ready (available in Europe and Australia only) Note: SiriusXM and DAB+ do not support traffic or weather.

Digital Signal Processing (DSP)    Yes

Fusion speaker, subwoofer and amplifier profiles preconfigured via DSP Yes

Fusion-Link Control (Wireless)    Yes

Bluetooth Wireless Technology Bluetooth audio streaming, music control (via devices compatible with A2DP/AVRCP 1.3 Bluetooth protocols)

SiriusXM-Ready                Yes

ANT® Technology             Yes

NMEA 2000® (Control via MFD - Fusion-Link)       Yes

Works with NRX Remotes             Yes

Fits DIN Cut-Out               Yes - requires adapter plate

Water Resistance (IP rating)         IPX6 and IPX7 from the front panel when installed correctly

Internal Amplifier             Class-D (minimum 4 Ohm impedance)

Peak Power        200 W max

Multi-Language User Interface   Bulgarian / Chinese (Simplified) / Chinese (Traditional) / Croatian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Italian / Japanese / Korean / Norwegian / Polish / Portuguese (BR) / Portuguese (PT) / Slovenian / Spanish / Swedish / Thai / Turkish

Auxiliary Inputs 1 x RCA input (AUX)

USB 2.0 Port       One USB 2.0 port (for phone charging / media playback)

SiriusXM              One SiriusXM port (requires optional SiriusXM Connect vehicle tuner, does not support traffic and weather)

AM / FM radio   One Motorola antenna connector port

Speaker Channels            2 x channels, 1 pair per zone (2 zone amplified)

RCA Pre-Out (Left, Right and Subwoofer)               2 zones (1 x L+R per zone, 1 x Sub per zone - All require external amplification)

Operating Voltage            +10.8V - 16V DC

DAB+ Ready        Fusion DAB+ module is required (sold separately). Only available where DAB or DAB+ broadcast is supported

Software Updates            Available via USB - from Fusion-Link app on a phone connected via USB or from a USB flashdrive.

Physical Dimensions: Width x Height x Depth (incl. Volume Encoder)        157mm x 68mm x 126.6mm [6-3/16" x 2-11/16" x 5"]

Mounting Dimensions: Width x Height x Depth   135mm x 52mm x 107.6mm [5-5/16" x 2-1/16" x 4-1/4"]
