Product Specifications
Frequency Response 10 Hz to 40 kHz (-3dB @ 4 Ohm rated power)
Peak Power Output 1500 W
Rated Power Output (4 Ohm) 100 W rms x 6 @ 14.4 V input < 1% THD + N (EIA/CEA-490A)
Rated Power Output (2 Ohm) 140 W rms x 6 @ 14.4 V input < 1% THD + N (EIA/CEA-490A)
Rated Power Output (4 Ohm Bridged) 280 W rms x 3 @ 14.4 V input < 1% THD + N (EIA/CEA-490A)
Input Sensitivity 0.3 V to 8 V rms, user adjustable
Input Impedance 7k Ohm nominal
High-Pass/Low-Pass Full Range Filter Yes, user selectable
Filter Cross-Over Frequency 32 Hz to 320 Hz, user adjustable
Bass-Boost 0 to 9 dB, user adjustable (zone 3 only)
Operating Voltage 10.8 V to 16 V dc
Remote Switch-On Yes - 6 V threshold
Current Consumption (Standby) < 1 mA @ 14.4 V input
Current Consumption (Idle) < 2.5 A @ 14.4 V input
Current Consumption (Max) 75 A @ 14.4 V input
Fuse Rating 3 x 40 A ATC Blade-Type (SAE J1171 Compliant)
Protection Circuits Reverse-Voltage, Input Under/Over Voltage, Over-Temperature, Output Short-Circuit
Operating Temperature Range 0 to 50°C (32 to 122°F)
Ingress Protection Rating Dry area installation only
Dimensions 420 mm (L) x 210 mm (W) x 57 mm (H) or 16-9-16" (L) x 8-1/4" (W) x 2-1/4" (H)
Weight 5.15 kg or 11.35 lb with cover
Warranty 3 years
